Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 381
An endless chain androllers, with a slat-ted platform, rollover a sprocket-wheel drivingshaft.The walking plat-form is elevated toan angle of about 372 MISCELLANEOUS DEVICES. … 1535. DOG-POWER MACHINE. —The plane of the track wheel is setat an angle of about 200, with itsunder edge bearing upon a frictionpulley. Shaft and fly-wheel, withcrank for operating churn.
Mechanical movements
