22 1. VERTICAL ENGINE, WITHBELL-CRANK LEVER, for stem-wheel boat. 222. INCLINED PADDLE-WHEEL.ENGINE, with upright crank con-nected beam for driving air pump.. … 223. DIAGONAL TWIN-SCREW EN-GINE, arranged so that the connecting rods--cross each other, thus economizing space.
