Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 80
234. C0MP0UN1> YACHT ENGINE, Her- reshoff model. Direct ^^y receiver pipe. End and longitudinal elevation. STEAM POWER. /I … 235. HIGH-SPEED TANDEM ^^^ COMPOUND ENGINE, Harrisburg model. 236. TANDEM COMPOUND ENGINE, Phoenix IronWorks model.A direct pipeconnection be-tween the highand low pressurecylinder.Mechanical movements
