Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 114
a ; W, water-regujatingvalve ; D, stop check to over-flow ; C, automatic check; W,water valve. EBERMAN INJECTOR.— The combining tube slidesfor regulating thelift and over-flo^\•. A single gravity checkvalve, D, closes the overflowwhen the current to the boileris established. 378. NATHAN INJECTOR.—A… … 379. LITTLE GIANTINJECTOR.—This modelhas two fixed tubes. Thecentral or combining tube ismovable for adjustment. Asingle automatic check valveregulates the overflow. CHECK VAI.V£-> VALVE seat
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
