672. PNEUMATIC HAM-MER.—-Constructed on simi-lar lines with No. 673, withthe addition of a counter-balance piston, C, which, by-its reaction and cushion, re- lieves the body of the tool and the hand from excessive jar. … 673. PNEUMATIC HAMMER.—F is the flexible hose con-nection. When T is pressed, compressed air enters through the piston valve and portsTo, into the cylinder, asindicated by the arrows inthe cut. The piston willfirst move to the top. Theeffective pressure is thatdue to the area of the pis-ton. When P…
