Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 199
708. RING ARMATURE.—Method of continuouswinding and sectionalconnections with thecommutator. The dot-ted lines are the circuitconnection with thebrushes. … 709. TWO-POLE OR SHUTTLE-SPOOLARMATURE.—Section of spool with end overwinding; usually made of cast iron.
Mechanical movements
