Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 218
785. FULL-RIGGED SHIP, with doubletopsails and staysails. i, flying-jib; 2,jib; 3, foretopmast staysail; 4, foresail; 5,mainsail; 6, cross-jacksail; 7, spanker; 14,main-topmast staysail; 15, mizzen-topmaststaysail; 16, lower foretopsail; 17, lower maintopsail; 18, lowermizzen-topsail; 19, upper…Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
