Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 291

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 291 — 1145;. POSITIVESHUTTLE MOTIONfor a narrow fabricloom. The shuttle hasa narrow recessed rackgeared through a set ofpinions to the recipro-cating rack. 1145^. A CURIOUS PADLOCK.—The key Is like a corkscrew. The circular recess in front contains a rotating cylinder with a spiral key wayand graduated… … Section XIIL HOROLOGICAL. Clock and Watch Movements and Devices.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
