Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 325

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 325 — 1280. SHAFT STEP ADJUSTMENT forspindles of millstones. 1281. ADJUSTABLE STEP BEARING,with hard bronze bush and step. A mor-tise through the iron base and a key drawnwith a screw extension and nut are for verti-cal adjustment. … 1282. COLLAR BEARING AND STEPfor a vertical shaft. The thrust sleeve ofbronze is split and should have a key to pre-vent rotation. MILL AND FACTORY APPLIANCES. 317

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
