An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 383 — -i r z^- It DOOR PUSH CHECK.—The spring closes the piston in the cylinder has a valve to allow quick inlet of air when opening a door, and a small hole adjustable at the bottom of the cylinder for slowly discharging the air. 1545. FOLDING LADDER.—The rounds arepivoted to the side pieces, which are… … 1546. SIMPLE COMBINATION LOCK. —A number of discs arranged on a spindlehaving a feather key. The discs are notchedto match the notches in the key so that theyreadily turn to be set to the register number torelease the spindle.
