I. GALLOWAYBOILER.—An in-ternally fired ovalflue,with small con-i^ ical tubes set diap:o-nallyacrossthe flue. 182. INTERNAL FIREDCYLINDRICAL TUBULARBOILER.—Lower shell slight-ly inclined to facilitate circula-tion. Fire surface of tubes^fire-box, and all of shell ex-posed to heat, divided by…
