Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 77
2 2 1. VERTICAL ENGINE, WITHBELL-CRANK LEVER, for stern-wheel boat. 2 2 2. INCLINED PADDLE-WHEELENGINE, with upright crank-con-nected beam for driving air pump. … 223. DIAGONAL TWIN-SCREW EN-GINE, arranged so that the connecting rodscross each other, thus economizing space.
Mechanical movements
