Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 101

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 101
344. FORRESTER ROTARY ENGINE.—A cylindrical block and guard wing swing on an ec-centric on the shaft. The guard wing slides in andoperates the ports of a two-port rotary valve, theouter shell of which is operated by levers and con-necting rods for reversing the engine. … 345. « KIPP ROTARY PISTONENGINE. — A broad pulley enclosingfour single-acting cylinders with op-posite pistons connected by yoked rods.A fixed crank pin and slide blockplaced eccentric to the pulley axis givesthe propelling force by displacing the pistons successively. Thesteam follows through…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
