Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 119

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 119
The trap is placedabove the water lineof the boiler. Theglobe is balancedon a weighted leverso that it rises whenempty and fallswhen filled withwater. The movement of the globe up and down trips valves thatalternately charge the globe with the water from a heating systemand discharges it into the…

Mechanical movements
