Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 121

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 121
418. HORIZONTAL SWING CHECKVALVE.—The disc is loose in the swingframe and may be reground tight by a socketwrench passed through the plug opening. … 419. GLOBE VALVE. «, the body.d^ the bonnet.g^ the spindle.hi the winged disc. ^, the spindle nut. e^ gland,y, gland nut.h, wheel.
