419. GLOBE VALVE. «, the body.d^ the bonnet.g^ the spindle.hi the winged disc. ^, the spindle nut. e^ gland,y, gland nut.h, wheel. … 420. EXHAUST STEAM HEAD. —The ex-haust steam is deflected by perforated discs and capplates, which separate the water to drip betweenthe inner and outer shell.
