Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 121

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 121
420. EXHAUST STEAM HEAD. —The ex-haust steam is deflected by perforated discs and capplates, which separate the water to drip betweenthe inner and outer shell. … 421. CENTRIFUGAL EXHAUST HEAD.—The exhaust steam head enters the drumtangentially, throwing the particles of wateragainst the outer surface to drip to the bottom, STKAM APPLIANCES. 115

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
