Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 140

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 140
471. FLUTTER WHEEL.—Much in use toback the log carriage of saw-mills. Efficiencyvery low. HYDRAULIC POWER AND DEVICES. 133 … 472. wheel. BARKER WHEEL.—A reaction waterThe reaction of the water escaping from the tangential orifices at the ends of the arms11 under the pressure of the water head in the hol- low shaft gives impulse to the wheel,efficiency. Very low
