Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 146

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 146
502. POWER OF WATER.—Apparatus for measuring the forceof a water jet when dischargedthrough a semicircular tube ortrough. The total force is measuredby the weight w. … 503. POWER OF WATER.—Appara-tus for measuring the force of a water jetwhen turned to a right angle by a benttrough, a^ A spring scale. The verticalforce is weighed on the platform scale,the horizontal force by the spring scale.

Mechanical movements
