Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 154

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 154
545. SIPHON and its operation.A, The siphon; H, G, cocks to be closed whenfirst filling; B,air chamber C, water seal; D, funnel. Theair that accu-mulates in the chamber, B, by the operation of the siphon, may be discharged byclosing cock C, opening cock D, and filling the chamber with water.Close D…
