Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 160

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 160
567. HYDRAULIC RAIL BENDER. —The plunger is moved with great forceby the pressure from a small pistonplunger operated by a hand lever, on thesame principle as with the hydraulicjack. It is suspended by the eyes, andcan be used for straightening or bendingrails on the track. … 568. HYDRAULIC RAIL PUNCH, constructed in the same line as the railbender and hydraulic press. The loopsare for suspending and to allow thepunch to be easily handled in any ^sition. 1^54 HYDRAULIC POWER AND DEVICES.
