Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 166

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 166
597. DOUBLE-BEAT PUMP VALVE, Cor-I nish model. The upper seat is supported by across-bar, in which is fixed the guide-pin thatI carries the valve. … 598. DOUBLE-BEAT PUMP VALVE orrelief valve.— The valve spindle ma}- beloaded by weight or spring. .xmmc;^^^mm;M^^^ i6o HYDRAULIC POWER AND DEVICES.
