Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 168

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 168
TANK, Miller model. In this form thesiphon is inverted, holding the water seal tobalance the water head in the tank in theuptake of the siphon. The cap over thelong end of the siphon is to seal the air inthe siphon until the sewage pressure isequal to the water-balanced leg. 604. AUTOMATIC FLUSH… … 605. ATOMIZER.—A small streamrunning down an incline is atomized atthe nozzle by a blast of air.

Mechanical movements
