Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 187

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 187
670. COMPRESSED AIR LIFT, Claytonmodel. Showing safety stop on the piston rod,which automatically stops the lift at any set pointby closing the air valve. 671. DUPLEX PNEUMATIC RIVETER. •— The striking piston, A, is en-cased in a striking cylinder, C,so that the tool, T, receives ablow alternately… … AIR POWER APPLIANCES. l8l

Mechanical movements
