Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 188

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 188
AIR POWER APPLIANCES. l8l … 672. PNEUMATIC HAM-MER.—Constructed on simi-lar lines with No. 673, withthe addition of a counter-balance piston, C, which, by-its reaction and cushion, re-lieves the body of the tool and the hand from excessive jar. 673. PNEUMATIC HAMMER.—F is the flexible hose con-nection. When T is pressed,…
