l82 AIR POWER APPLIANCES. … COMPRESSED AIR SHEEP-SHEARING MACHINE.—Asmall piston vibrates and oper-ates the cutters through a leverwith a diagonal slot in which apin in the piston-rod head slides.An arm on the piston rod oper-ates the alves.
