Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 192

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 192
IT^ 691. AIR AND GASOLINE BRAZINGAPPARATUS.—A small attached pumpforces air into a tank holding a small quan-tity of gasoline. A gauge shows the airpressure. From the top of the tank a pipeextends to two oppositely placed Bunsen burnerswith valves for regulating the flame. Swivels inthe pipe allow…
