Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 198

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 198
second winding of the field magnets is m series ordirect connection with the outer circuit. The shuntwinding should be small wire. S, Shunt connected with armature brush holders; S, large wire field winding in main circuit 716. CONSEQUENT-POLECOMPOUND GENERATOR. —The opposite field pieces arewound… … 192 ELECTRIC POWER AND CONSTRUCTION.
