750. ELECTRIC FURNACE, Cowleshopper model. The upper electrode is avertical carbon tube fixed to the hopper.The lower electrode is a larger carbon tubefixed to the furnace floor. The tubes arebanked with carbon and lime. The chargeis fed down from the hopper by a barbedrod, reciprocated by a crank.… … 751. ELECTRIC WELDING PLANT.—The secondary coil is the heavy bar ofcopper enclosing the primary coil towhich the clamps are attached. Themagnetic material is in the form of coilsof iron wire wound around the primarycoil and copper hoop. C, clamp arms. D, pieces to be welded. Q ctf vvifAo nj HiQH…
