Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 209

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 209
757. ELECTRIC ROCK DRILL, GeneralElectric Co.s model. A series of electric coils arefixed along the cylinder. The iron plunger traversesthe interior of the coils, which are charged succes-sively by the electric current through traverse brusheson a straight commutator. 202 ELECTRIC POWER AND… … 758. ELECTRIC FAN.—The motor isconcealed in the central chamber, the middlesection of which revolves with the arms. J

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
