Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 217

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 217
786. FULL-RIGGED SHIP.—Square sailson fore, main, and mizzen mast, with a fore andaft sail on mizzen mast Three jibs, i, flying-jib; 2, jib; 3, foretopmast-staysail; 4, foresail;5, mainsail; 6, cross-jacksail; 7, spanker; 9,foietopsail; 10, maintopsail; 11, mizzentopsail; 22, foretopgallantsail;… … g ROPE KNOTS AND HITCHES.788. CLOVE HITCH. 789. HALF-HITCH.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
