shaft is the driver, and has a small longitudinal motion by a clutch and lever to shift the position of the blades. Theouter-end sleeve is fast on the driving shaft, andcarries the blades in sockets on each side of itscentre. A hollow short shaft, free on the driv-ing shaft, but fixed…
