Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 229

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 229
859. ELECTRIC PHAETON.—The motors are fixed to aframe under the floor of thephaeton, with their pinionsmeshing with an inside spurgear on each wheel. Thebatteries are under the seatand extension box over thedriving wheels. 860. … ELECTRIC BROUGHAM. The same general arrange-ment of the motor as inNo. 859, only that the bat-teries are stored under thefloor.
