Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 233

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 233
thetank, J. The wick G carries water to the car-bide by capillary action and pressure from grav-ity. The gas is aerated in the burner. Thevalve at I regulates the flow of water, which isalso retarded by the gas pressure in the carbidechamber. 880. BICYCLE LAMP.—W, bulls-eye lens. Air enters at O,… … 88oa. AIR SHIP.—General form of those inuse that have had any suc-cess. Too many come togrief and they should be awarning to the ambitioussoarer, to learn what hispredecessors have done. SSob. RAILROAD GATE operated by com-pressed air.—A hand pump in the gate housecompresses air which is…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
