Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 245

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 245
ooth of its gear. 930. ACCELERATED CIRCULAR MaTION by a volute gear. The pinion P andguide disc R move along the feathered shaft C,following the rail guide, and returns by reversalof the motion of the driving shaft C. 931. ROLLER-BEARING GEAR TEETH. —A double-flanged wheel with… … 932. BALL GEAR with traverse pinions. Hasa very limited traverse of the pinions. 933. SPIRAL GEARING.—V gearing, in whichthe teeth are at a small angle with the plane of rota-tion, makes a perfectly silent transmission of power.

Mechanical movements
