Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 258

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 258
992J. CHANGEABLE MOTIONGEAR.—Two or more changes of motionby bevel gear may be made by moving apinion along a feathered shaft at an anglewith the change gear shaft. 252 GEARING.

Mechanical movements
