Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 271

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 271
1057. INTERMITTENT MOTION of a seg-mental-toothed wheel by the revolution of a seg-mental barrel or ring. … 1058. INTERMITTENT MOTION of a pin-tooth wheel by the revolution of an in-dented tooth on a pinion. 1059. INTERMITTENT MOTION of a toothedwheel by the revolution of a pinion with a singlerecessed tooth.

Mechanical movements
