Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 274

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 274
1074. SIX RADIAL GROOVED TRAMMELand triangular shaft arms, driving or beingdriven by a shaft out of line. The frictionrollers give freedom of motion to either gear. … 1075. RECTILINEAR RECIPROCAT-ING MOTION of a bar, from continuous cir-cular motion of a bent shaft.

Mechanical movements
