Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 294

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 294
arrel. G is the drivingspur gear. The larger ratchet has a fixedcheck pawl, T; is loose on the arbor, but at-tached to the gear wheel by a curved spring,^ S, S. The smaller ratchet is fixed to the UJi^lLJ winding barrel and arbor. The spring and pawl R are pivoted to the larger ratchet, and stop… … 2SS HOROLOGICAL. rm^pm

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
