Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 299

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 299
1191. WATCH STOP.—The number of turns of theratchet pinion is limited by the number of teeth in thestop. The pin moves one tooth for each turn. 1192. STEM-WINDINGMOVEMENT of a watch. Themovement of the lever with anarm outside of the rim locks aclutch on the hand gear. Thethird arm of the lever is… … HOROLOGICAL. 293

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
