Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 300

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 300
HOROLOGICAL. 293 … 1193. PIN-GEARED WATCH STOP. —The winding stops at the convex tooth of the stop. 1194. WATCH TRAIN. <?, key stem. ^, barrel and spring. c^ e^ h, i, pinions. d, h, spur wheels. /, /, pallets and escapement. k, lever and balance wheel. 1194a. EQUATED SUNDIAL.—The curved bulbs onthe shadow stile…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
