Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 334

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 334
he set rings at theback of the die. A circular spring throws out the cutters. Cross sec-tion. 1343. Front view. 1344. Longitudinal section, 1345. Outside view. 1346. UNIVERSAL CHUCK, for eccentric turning. The dividedgear plate and chuck-ing screw are re-volved and held atany division by thespring…
