Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 335

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 335
1352. GIG SAW.—The spring a gives tension tothe saw running between guide frames, and operatesvmmM, by crank and connecting rod. … 1353. BAND SAW, for sawing metals.The frame and third wheel are set back to giveroom for large plates.
