Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 337

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 337
1358. PORTABLE DRILL, rope trans,mission and flexible shaft. One continuousrope over driving pulley, two double sheavesanchored, and flexible shaft pulley; allow-ing the driving sheave of the flexible shaftto be anchored in any position, and fortightening the driving rope. 1359. MULTIPLE DRILLING… … 1360. MULTIPLE DRIL-LING MACHINE.—For drill-ing a number of holes in flangesat one time. The drill chucksare adjusted in a spider for anysize circle and connected to the- driving head with jointed rods.

Mechanical movements
