Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 342

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 342
1384. FLEXIBLE UNIVERSAL STEAMJOINT.— Hampson model. The steam flowsthrough the thick arms of the Ys, which haveground joints. 1385. BYE PASS COCK OR VALVE.—To allow of a small delivery vvhen thelarge valve is closed, or for relief of press-ure against a large valve. … 1386. SIGHT-FEED LUBRICATOR.—The amount of feed is seen by the frequency of drops atthe sight hole. Adjusted by a needle-point valve withmilled head and screw.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
