Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 342

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 342
1387. SCREW MOVEMENT, for the tailstock of a lathe. The spindle moves m a keyslot to prevent turning. The screw has acollar and is shouldered on the outside by thewheel hub. The back end of spindle has athread acting as a nut on the driving screw. … verses around the shaft to be centered.1389, End view. 1388. CENTERINGTOOL. Used for scratch-ing the centre on roundshafting or rods. Theslotted arm E swings onthe spindle A, as it tra- 33^ MILL AND FACTORY APPLIANCES.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
