Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 375

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 375
i53i«- OMNI-TELEMETER.—For obtaining the distance of an ob-ject by two observations on a line atright angles. A, direct line ofsight through the half silvered mir-ror D; X, reflected line of sight at90° or variable by the mirrors D, F.The lever L varies the angle of themirror, F, by means of the… … 1531&. ODONTOGRAPH. — Ascribe template for laying out thecurves of the teeth of gear wheels.
