372 MISCELLANEOUS DEVICES. … 1535. DOG-POWER MACHINE.—The plane of the track wheel is setat an angle of about 20°, with itsunder edge bearing i^pon a frictionpulley. Shaft and fly-wheel, withcrank for operating churn.
