Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 395

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 395
1612. FREIGHT LOCOMOTIVE.—Consolidation type. … 1613. CENTRE VALVE, for a gas house. Afour-part valve for a purifier. Arranged to cut outany one of four purifier pans. 1614. Plan showing position of valve. MISCELLANEOUS DEVICES. 389

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
