Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 397

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 397
39° MISCELLANEOUS DEVICES. … on a set of dials adapted to separate dial readings. 1620. WET GAS METER. —Gas entersthrough the hollow axis of the four compartmentsof the drum in a pipe, which turns up just abovethe water level and fills each compartment suc-cessively, and by its pressure causes the drum torevolve in the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
